Microchip Technology PIC16F57-I/P
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.31 | $1.31 |
| 15+ | $1.27 | $19.05 |
| 25+ | $1.24 | $31.00 |
| 50+ | $1.17 | $58.50 |
| 100+ | $1.04 | $104.00 |
| N+ | $0.21 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | PIC® 16F |
| Packaging | Tube | Tube |
| Core Processor | PIC |
| Core Size | 8-Bit |
| Speed | 20MHz |
| Connectivity | - |
| Peripherals | POR, WDT |
| Number of I/O | 20 |
| Program Memory Size | 3KB (2K x 12) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 72 x 8 |
| Voltage - Supply (Vcc/Vdd) | 2V ~ 5.5V |
| Data Converters | - |
| Oscillator Type | External |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Supplier Device Package | 28-PDIP |
| Package / Case | 28-DIP (0.600", 15.24mm) |
| ROHS |  |
The Microchip PIC16F57 is a classic 8-bit microcontroller in a 28-pin DIP package. It operates from 2V to 5.5V and runs at up to 20MHz, offering a balance of performance and simplicity. With 3KB Flash and 72 bytes RAM, it includes essential features like WDT and Power-on Reset. Its through-hole package makes it easy to prototype and integrate into industrial or educational projects.
- Wide voltage range (2V-5.5V) – flexible for various power supply designs.
- 28-pin DIP package – easy to solder and replace in field applications.
- 20MHz speed – sufficient for real-time control loops.
- Simple architecture – reduces development time for basic control tasks.
Industrial Control Panels
The 28-pin DIP package provides ample I/O for relay control and status LEDs in industrial machinery.
Automotive Aftermarket
With 5.5V operation and 20MHz speed, it can handle simple engine monitoring or dashboard displays.
Home Automation
Its 3KB Flash is sufficient for smart switch or thermostat control logic, with WDT ensuring reliability.
Test Equipment
The wide voltage range allows integration into benchtop multimeters or signal generators.
HVAC Systems
It can manage fan speed control and temperature sensing in thermostats, with DIP package easing field servicing.
Educational Kits
The DIP package is breadboard-friendly, making it ideal for teaching microcontroller fundamentals.
- Q: What is the operating voltage range?
- A: It operates from 2V to 5.5V, supporting both 3.3V and 5V systems.
- Q: What is the maximum speed?
- A: The PIC core runs at up to 20MHz, providing adequate performance for control applications.
- Q: How much program memory does it have?
- A: It includes 3KB of Flash (2K x 12 words) for code storage.
- Q: What package is available?
- A: It comes in a 28-pin DIP package (0.600" width), ideal for prototyping and through-hole assembly.
- Q: Does it have a watchdog timer?
- A: Yes, it features a WDT and Power-on Reset for reliable operation.
