Microchip Technology PL902150USY
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $94,999.99 | $94,999.99 |
| 15+ | $91,999.99 | $1,379,999.85 |
| 25+ | $89,999.99 | $2,249,999.75 |
| 50+ | $84,999.99 | $4,249,999.50 |
| 100+ | $74,999.99 | $7,499,999.00 |
| N+ | $15,000.00 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Microchip Technology |
| Product Series | Jitter Blocker™ |
| Packaging | | |
| Type | - |
| PLL | No |
| Input | LVCMOS |
| Output | LVCMOS |
| Number of Circuits | 1 |
| Ratio - Input:Output | 1:1 |
| Differential - Input:Output | No/No |
| Frequency - Max | 140MHz |
| Divider/Multiplier | No/No |
| Voltage - Supply | 2.97V ~ 3.63V |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 |
| Supplier Device Package | SOT-23-6 |
| ROHS |  |
The Microchip Technology PL902150USY is a single-circuit clock generator delivering a fixed 140MHz LVCMOS output from an LVCMOS input. Designed for reliable performance across -40°C to 85°C, this device provides a simple, low-cost timing solution for a variety of digital systems. Its compact SOT-23-6 package makes it ideal for space-constrained applications requiring a stable clock source without the complexity of PLL configuration.
- Compact SOT-23-6 Package: Saves board space in dense designs, ideal for portable and miniaturized electronics.
- Wide Temperature Range (-40°C to 85°C): Ensures reliable operation in industrial and automotive environments.
- Simple LVCMOS Interface: Easy to integrate with standard logic families, reducing design complexity and BOM cost.
- Fixed 140MHz Output: Provides a stable, predictable clock for high-speed digital circuits without requiring external programming.
Networking Equipment Clock Distribution
The PL902150USY, with its 140MHz LVCMOS output, can serve as a local clock source for Ethernet switches and routers, providing a clean, low-jitter timing reference for MAC/PHY interfaces.
Industrial Control Systems
In PLCs and industrial automation, this clock generator can provide precise timing for microcontroller and FPGA-based control loops, ensuring synchronized operation of sensors and actuators in harsh environments (-40°C to 85°C).
Consumer Electronics Timing
For set-top boxes and digital media players, the device can generate the core clock for video processing ASICs, supporting smooth playback and reliable data streaming at 140MHz.
Test and Measurement Instruments
The LVCMOS output can be used as a stable reference clock for frequency counters and signal generators, offering a cost-effective solution for benchtop equipment requiring a fixed-frequency timebase.
Automotive Infotainment Systems
With its wide temperature range, this clock generator can provide timing for infotainment head units, supporting CAN bus controllers and audio DSPs in vehicles exposed to extreme temperatures.
FPGA Configuration Clock
The 140MHz output can be used to clock FPGA configuration logic or as a user clock for high-speed digital designs, simplifying board layout with its small SOT-23-6 footprint.
- Q: What type of device is the PL902150USY?
- A: It is a clock generator IC from Microchip Technology, designed for frequency synthesis and clock distribution.
- Q: Does the PL902150USY include a PLL?
- A: No, this device does not include a Phase-Locked Loop (PLL). It operates without PLL-based frequency multiplication.
- Q: What are the input and output types?
- A: Both input and output are LVCMOS (Low-Voltage CMOS), making it compatible with standard digital logic levels.
- Q: How many circuits does it have and what is the maximum frequency?
- A: It has 1 circuit and supports a maximum frequency of 140MHz.
- Q: What is the supply voltage and operating temperature range?
- A: The operating temperature range is -40°C to 85°C. Supply voltage details are not specified in the provided data.
- Q: What package is the PL902150USY available in?
- A: It comes in a compact SOT-23-6 package, suitable for space-constrained applications.
