Nisshinbo Micro Devices Inc. RP114K181D-TR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.84 | $0.84 |
| 15+ | $0.81 | $12.15 |
| 25+ | $0.79 | $19.75 |
| 50+ | $0.75 | $37.50 |
| 100+ | $0.66 | $66.00 |
| N+ | $0.13 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Product Series | RP114x |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.25V |
| Voltage - Output (Min/Fixed) | 1.8V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.39V @ 300mA, 0.39V @ 300mA |
| Current - Output | 300mA |
| Current - Quiescent (Iq) | 75 µA |
| Current - Supply (Max) | - |
| PSRR | 75dB (1kHz) |
| Control Features | Enable |
| Protection Features | Over Current |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-UDFN Exposed Pad |
| Supplier Device Package | DFN(PL)1010-4 |
| ROHS |  |
The RP114K181D-TR from Nisshinbo is a high-performance 300mA low dropout linear regulator delivering a fixed 1.8V output. Its ultra-compact DFN(PL)1010-4 package and 75 µA quiescent current make it an excellent choice for battery-powered and space-constrained applications. With 75dB PSRR at 1kHz and a low dropout voltage of 0.39V, it ensures clean, stable power for noise-sensitive circuits.
- Extended Battery Life: Ultra-low 75 µA quiescent current minimizes standby power consumption in portable devices.
- Clean Power Delivery: 75dB PSRR at 1kHz effectively filters supply noise for sensitive analog and RF circuits.
- Space-Saving Design: The 1.0mm x 1.0mm DFN package enables ultra-compact PCB layouts for wearables and IoT modules.
- High Efficiency at Load: Low 0.39V dropout at 300mA maintains regulation even with low input margins.
Portable Battery-Powered Devices
The low 75 µA quiescent current and 300mA output make it ideal for extending battery life in wearables, IoT sensors, and handheld instruments where every microamp matters.
Noise-Sensitive RF and Audio Circuits
With 75dB PSRR at 1kHz, this LDO effectively suppresses power supply ripple, ensuring clean power for RF transceivers, audio codecs, and precision analog front-ends.
Compact Space-Constrained Designs
The DFN(PL)1010-4 package (1.0mm x 1.0mm) is perfect for space-limited applications like earbuds, smart watches, and medical patches where board area is critical.
Microcontroller Power Supply
Provides stable 1.8V rail for low-power MCUs and digital logic, with fast transient response to handle dynamic load changes during processing tasks.
Industrial Sensor Interfaces
Reliable 300mA output with low dropout ensures consistent performance in industrial sensors and transmitters operating from 3.3V or 3.6V battery stacks.
Always-On Power Domains
The ultra-low quiescent current makes it suitable for always-on domains in smart home devices, maintaining standby functionality without draining the main battery.
- Q: What is the output voltage of the RP114K181D-TR?
- A: The fixed output voltage is 1.8V.
- Q: What is the maximum output current?
- A: It can deliver up to 300mA.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; refer to the datasheet.
- Q: What is the dropout voltage?
- A: Dropout voltage is 0.39V at 300mA output.
- Q: What is the quiescent current?
- A: The quiescent current is 75 µA.
- Q: What package is available?
- A: It comes in a DFN(PL)1010-4 package.
