Runic Technology RS3002-5.0YSF3
Regular price
$0.64
Regular price
$0.67
Sale price
$0.64
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.64 | $0.64 |
| 15+ | $0.62 | $9.30 |
| 25+ | $0.60 | $15.00 |
| 50+ | $0.57 | $28.50 |
| 100+ | $0.50 | $50.00 |
| N+ | $0.10 | Price Inquiry |
Shipping calculated at checkout.
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Runic Technology |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 36V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 1.8V @ 150mA |
| Current - Output | 150mA |
| Current - Quiescent (Iq) | 8 µA |
| Current - Supply (Max) | - |
| PSRR | 57dB ~ 54dB (217Hz ~ 1kHz) |
| Control Features | Enable |
| Protection Features | Over Temperature |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 |
| ROHS |  |
The RS3002-5.0YSF3 from Runic Technology is a 150mA LDO regulator with a fixed 5V output. It features an ultra-low quiescent current of 8µA and a dropout voltage of 1.8V at full load. The SOT-23-3 package makes it suitable for compact, battery-operated devices requiring a stable 5V rail.
- Ultra-low quiescent current: 8µA extends battery life in standby mode.
- Standard 5V output: Compatible with legacy TTL logic and analog circuits.
- Small package: SOT-23-3 is easy to integrate in space-limited designs.
- Cost-effective: Ideal for high-volume consumer applications.
Battery-Powered Microcontrollers
5V rail for MCUs in remote sensors, with 8µA quiescent current for long standby.
Industrial Logic Level Shifters
Stable 5V supply for 5V TTL logic in legacy industrial equipment.
Portable Instrumentation
SOT-23-3 package fits compact handheld devices requiring 5V for analog front-ends.
Automotive Sensor Interfaces
57dB PSRR at 217Hz filters PWM noise from automotive lighting systems.
Consumer Appliances
Simple 5V regulation for touch panels and display drivers in home appliances.
Low-Power Audio Amplifiers
150mA capacity supports small audio amps with 5V supply for clear output.
- Q: What is the output voltage?
- A: Fixed 5V output.
- Q: What is the maximum current?
- A: 150mA.
- Q: What is the input voltage range?
- A: Not specified in provided data; typically up to 12V for 5V LDOs.
- Q: What is the dropout voltage?
- A: 1.8V at 150mA.
- Q: What is the quiescent current?
- A: 8µA.
- Q: What package is it?
- A: SOT-23-3.
Base Product Number ：
RS3002-5.0
RS3002-5.0YSF3.pdf
