EPSON S1C17W18F101100
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $5.73 | $5.73 |
| 15+ | $5.55 | $83.25 |
| 25+ | $5.43 | $135.75 |
| 50+ | $5.13 | $256.50 |
| 100+ | $4.52 | $452.00 |
| N+ | $0.90 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | EPSON |
| Product Series | |
| Packaging | Tray | |
| Core Processor | S1C17 |
| Core Size | 16-Bit |
| Speed | 4.2MHz |
| Connectivity | I2C, IrDA, SPI, UART/USART |
| Peripherals | LCD, PWM, RFC, WDT |
| Number of I/O | 67 |
| Program Memory Size | 96KB (96K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 8K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.2V ~ 3.6V |
| Data Converters | A/D 9x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 128-TQFP15 (14x14) |
| Package / Case | 128-TQFP |
| ROHS |  |
The EPSON S1C17W18F101100 is a low-power 16-bit microcontroller featuring an S1C17 core running at 4.2MHz. It integrates an LCD controller, PWM, RFC, and watchdog timer, making it a versatile choice for display-centric embedded systems. With 96KB flash and 8KB RAM, it supports complex firmware in a 128-TQFP package, operating from 1.2V to 3.6V.
- Ultra-low voltage operation (1.2V) – Enables direct battery operation with minimal power conversion losses.
- Integrated LCD driver – Reduces external components and simplifies display interface design.
- Rich peripheral set (PWM, RFC, WDT) – Provides flexibility for motor control, wireless triggering, and system supervision.
- Wide temperature range (-40°C to 85°C) – Suitable for industrial and automotive environments.
Portable Medical Devices
The low 1.2V operation and LCD driver enable compact glucose meters and thermometers with direct display readouts.
Battery-Powered Sensors
With 96KB flash and 8KB RAM, it can log sensor data while the PWM and RFC modules handle periodic wake-ups and wireless triggers.
Industrial Control Panels
The 128-TQFP package provides enough I/O for keypads and indicators, while the WDT ensures reliable operation in noisy environments.
Smart Home Thermostats
LCD output and low power consumption allow always-on temperature display with minimal battery drain.
Wearable Fitness Trackers
The small footprint and 1.2V operation support slim designs, and the RFC module enables simple wireless communication.
Automotive Aftermarket Gauges
Operating from -40°C to 85°C, it can drive segmented LCDs in dashboards with PWM for backlight control.
- Q: What is the operating voltage range of the S1C17W18F101100?
- A: It operates from 1.2V to 3.6V, suitable for battery-powered devices.
- Q: What is the maximum CPU speed?
- A: The S1C17 core runs at up to 4.2MHz.
- Q: Does it have an LCD controller?
- A: Yes, it includes an LCD driver, making it ideal for display applications.
- Q: What is the package type?
- A: It comes in a 128-TQFP package.
