Texas Instruments SN74LV125ADGVR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.29 | $0.29 |
| 15+ | $0.29 | $4.35 |
| 25+ | $0.28 | $7.00 |
| 50+ | $0.26 | $13.00 |
| 100+ | $0.23 | $23.00 |
| N+ | $0.05 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | 74LV |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Part Status | Active |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 4 |
| Number of Bits per Element | 1 |
| Input Type | - |
| Output Type | 3-State |
| Current - Output High, Low | 16mA, 16mA |
| Voltage - Supply | 2V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 14-TFSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-TVSOP |
| ROHS |  |
The SN74LV125ADGVR is a quad non-inverting buffer from Texas Instruments, part of the 74LV logic family. It features four independent buffers with 3-state outputs, enabling bus-oriented applications. Operating from 2V to 5.5V, it is compatible with both 3.3V and 5V systems. Each output can source or sink 16mA, suitable for driving a variety of loads. The 14-TFSOP package is thin and compact, ideal for space-constrained designs. Typical applications include bus buffering, level shifting, and signal conditioning in industrial and consumer electronics.
- Low Power 74LV Family: Reduces power consumption in battery-operated devices.
- 3-State Outputs: Enables bus sharing and prevents data contention.
- 16mA Output Drive: Suitable for driving relays and other moderate loads.
- Thin TFSOP Package: Saves space in compact electronic designs.
Low-Power Bus Buffering
Use the SN74LV125ADGVR in battery-powered devices to buffer data buses. The 74LV family's low power consumption is ideal for extending battery life.
Level Shifting in Mixed-Voltage Systems
Interface between 3.3V and 5V components. The wide supply range allows operation at either voltage, simplifying design.
Peripheral Isolation in Microcontroller Systems
Use the 3-state outputs to isolate peripherals from the microcontroller bus, preventing conflicts when multiple devices share the same lines.
Industrial Control Signal Buffering
Buffer control signals in industrial automation. The 16mA output current can drive relays and other actuators.
Memory Interface Buffering
Drive address and data lines in memory systems. The buffer provides the necessary fan-out and signal integrity.
Automotive Electronics
With a wide temperature range, it is suitable for automotive control units, buffering signals in harsh environments.
- Q: What is the logic family of the SN74LV125ADGVR?
- A: It belongs to the 74LV logic family, offering low voltage and low power operation.
- Q: What is the function of this IC?
- A: It is a quad (4-channel) non-inverting buffer with 3-state outputs.
- Q: What is the output type?
- A: It features 3-state outputs, allowing connection to shared buses.
- Q: What is the operating voltage range?
- A: It operates from 2V to 5.5V, compatible with 3.3V and 5V systems.
- Q: What is the output current capability?
- A: It can source and sink 16mA, suitable for driving moderate loads.
- Q: What package is available?
- A: It comes in a 14-TFSOP package, a thin and compact form factor.
