Texas Instruments SN74LV367ADGVR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.22 | $1.22 |
| 15+ | $1.18 | $17.70 |
| 25+ | $1.15 | $28.75 |
| 50+ | $1.09 | $54.50 |
| 100+ | $0.96 | $96.00 |
| N+ | $0.19 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | 74LV |
| Packaging | Marketplace | Cut Tape (CT) |
| Part Status | Active |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 2 |
| Number of Bits per Element | 2, 4 (Hex) |
| Input Type | - |
| Output Type | 3-State |
| Current - Output High, Low | 16mA, 16mA |
| Voltage - Supply | 2V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-TFSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TVSOP |
| ROHS |  |
The SN74LV367ADGVR from Texas Instruments is a 2-channel, non-inverting buffer with 3-State outputs. Operating from 2V to 5.5V, it provides flexibility for both low-voltage and standard logic systems. Each channel can sink or source 16mA, suitable for driving LEDs or moderate bus loads. The 16-TFSOP package is compact for space-constrained PCBs. This buffer is widely used in level shifting, bus isolation, and signal buffering in consumer, industrial, and automotive applications.
- Wide 2V to 5.5V Supply: Supports multiple logic levels, reducing the need for multiple buffer types.
- Low Power Consumption: Ideal for battery-operated devices where power efficiency is critical.
- 3-State Outputs: Provides bus isolation and prevents signal contention.
- Compact TFSOP Package: Saves PCB area in dense designs.
Mixed-Voltage Level Shifting
With a 2V to 5.5V range, this buffer can translate signals between 2.5V, 3.3V, and 5V logic domains, simplifying multi-voltage designs.
Battery-Powered Consumer Electronics
Its low-voltage operation and low power consumption make it ideal for handheld devices like remote controls and portable sensors.
Bus Isolation in Microcontroller Systems
The 3-State outputs allow the microcontroller to disconnect from peripherals, reducing power consumption in sleep modes.
Signal Buffering for LED Displays
The 16mA drive capability can directly drive LED segments or small displays, reducing the need for external drivers.
Automotive Body Electronics
With a -40°C to 85°C range, it suits automotive body control modules for door locks, windows, and lighting.
- Q: What is the logic family of the SN74LV367ADGVR?
- A: It belongs to the 74LV (Low-Voltage) logic family, optimized for low-power operation.
- Q: What is the function of this IC?
- A: It is a 2-channel, non-inverting buffer with 3-State outputs.
- Q: How many channels does it have?
- A: It has 2 channels, suitable for buffering two independent signals.
- Q: What is the output type?
- A: The outputs are 3-State, allowing high-impedance control for bus applications.
- Q: What is the operating voltage range?
- A: It operates from 2V to 5.5V, covering both low-voltage and standard 5V systems.
- Q: What package is available?
- A: It comes in a 16-TFSOP (0.173", 4.40mm Width) package.
