STMicroelectronics STM32F101RBH6
Regular price
$14.42
Regular price
$3.60
Sale price
$14.42
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $14.42 | $14.42 |
| 15+ | $3.31 | $49.65 |
| 25+ | $3.24 | $81.00 |
| 50+ | $3.06 | $153.00 |
| 100+ | $2.70 | $270.00 |
| N+ | $0.54 | Price Inquiry |
Shipping calculated at checkout.
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | STMicroelectronics |
| Product Series | STM32F1 |
| Packaging | Tray | NULL |
| Core Processor | ARM® Cortex®-M3 |
| Core Size | 32-Bit Single-Core |
| Speed | 36MHz |
| Connectivity | I2C, IrDA, LINbus, SPI, UART/USART |
| Peripherals | DMA, PDR, POR, PVD, PWM, Temp Sensor, WDT |
| Number of I/O | 51 |
| Program Memory Size | 128KB (128K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 16K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2V ~ 3.6V |
| Data Converters | A/D 16x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 64-TFBGA (5x5) |
| Package / Case | 64-TFBGA |
| ROHS |  |
The STM32F101RBH6 from STMicroelectronics is an ARM Cortex-M3 based MCU running at 36MHz. It offers 128KB flash and 16K RAM in a 64-TFBGA package. With DMA, PVD, PWM, and a temperature sensor, it is designed for cost-effective industrial and consumer applications requiring balanced performance.
- Efficient Cortex-M3 core: 36MHz with low power consumption.
- Rich analog features: Temp sensor and PVD for monitoring.
- Compact BGA package: 64-TFBGA saves board space.
- Wide voltage range: 2V to 3.6V for flexible power.
Industrial Control Panels
DMA and PWM enable efficient control of relays and actuators.
Building Automation
Low power and wide voltage range suit HVAC and lighting controllers.
Portable Instruments
Small TFBGA package and 16K RAM support compact data loggers.
Motor Drives
PWM and temp sensor provide basic motor control with thermal monitoring.
Smart Sensors
Multiple communication interfaces allow easy integration with gateways.
- Q: What core does it use?
- A: It uses the ARM Cortex-M3 core.
- Q: What is the maximum frequency?
- A: It operates at 36MHz.
- Q: How much flash memory is available?
- A: It has 128KB of flash memory.
- Q: What is the package type?
- A: It is available in a 64-TFBGA package.
Base Product Number ：
STM32F101RBH6
STM32F101RBH6.pdf
