STMicroelectronics STM32F103ZFH6
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $19.26 | $19.26 |
| 15+ | $12.66 | $189.90 |
| 25+ | $12.38 | $309.50 |
| 50+ | $11.70 | $585.00 |
| 100+ | $10.32 | $1,032.00 |
| N+ | $2.06 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | STMicroelectronics |
| Product Series | STM32F1 |
| Packaging | Tray | NULL |
| Core Processor | ARM® Cortex®-M3 |
| Core Size | 32-Bit Single-Core |
| Speed | 72MHz |
| Connectivity | CANbus, I2C, IrDA, LINbus, SPI, UART/USART, USB |
| Peripherals | DMA, Motor Control PWM, PDR, POR, PVD, PWM, Temp Sensor, WDT |
| Number of I/O | 112 |
| Program Memory Size | 768KB (768K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 96K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2V ~ 3.6V |
| Data Converters | A/D 21x12b; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 144-LFBGA (10x10) |
| Package / Case | 144-LFBGA |
| ROHS |  |
The STM32F103ZFH6 from STMicroelectronics is a high-density 32-bit microcontroller based on the ARM Cortex-M3 core, operating at up to 72MHz. It features 768KB of flash memory and 96KB of SRAM, making it suitable for complex applications. With a supply voltage range of 2V to 3.6V and a comprehensive set of peripherals including DMA, Motor Control PWM, PDR, POR, PVD, PWM, and a temperature sensor, this MCU is a versatile choice for industrial, medical, and consumer applications. The 144-LFBGA package offers a compact footprint for space-constrained designs.
- Large Memory Capacity: 768KB flash and 96KB RAM support complex firmware and data buffering.
- Motor Control Ready: Dedicated PWM timers and ADC features simplify the implementation of advanced motor control algorithms.
- Comprehensive Protection: Includes PDR, POR, and PVD for reliable power management and system stability.
- Mature Ecosystem: The STM32F1 series is widely adopted, offering extensive software libraries and community support.
Advanced Motor Control
The dedicated Motor Control PWM and 72MHz Cortex-M3 core enable precise field-oriented control of AC and DC motors in industrial drives.
Medical Monitoring Devices
With 768KB flash and 96KB RAM, it can run complex algorithms for patient monitoring, while the PVD ensures stable operation during voltage dips.
Building Automation
Its rich peripheral set, including multiple timers and communication interfaces, makes it suitable for HVAC controllers and access control panels.
Consumer Robotics
The combination of processing power, memory, and PWM channels supports multi-axis robot control and sensor fusion in hobbyist and educational robots.
Power Conversion
The high-resolution timers and ADC capabilities allow for efficient control of switch-mode power supplies and inverters.
Point-of-Sale Terminals
The large memory and robust feature set support secure transaction processing and peripheral connectivity in POS systems.
- Q: What is the maximum clock speed?
- A: The STM32F103ZFH6 runs at up to 72MHz.
- Q: How much flash memory does it have?
- A: It has 768KB of flash memory.
- Q: What is the package type?
- A: It is available in a 144-LFBGA package.
- Q: Does it have a temperature sensor?
- A: Yes, it includes an internal temperature sensor.
