STMicroelectronics STM32F469AIH6
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $24.02 | $24.02 |
| 15+ | $15.79 | $236.85 |
| 25+ | $15.44 | $386.00 |
| 50+ | $14.59 | $729.50 |
| 100+ | $12.87 | $1,287.00 |
| N+ | $2.57 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | STMicroelectronics |
| Product Series | STM32F4 |
| Packaging | Tray | |
| Core Processor | ARM® Cortex®-M4 |
| Core Size | 32-Bit Single-Core |
| Speed | 180MHz |
| Connectivity | CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, SAI, SDIO, SPI, UART/USART, USB, USB OTG |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT |
| Number of I/O | 114 |
| Program Memory Size | 2MB (2M x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 384K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.7V ~ 3.6V |
| Data Converters | A/D 24x12b; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 169-UFBGA (7x7) |
| Package / Case | 169-UFBGA |
| ROHS |  |
The STM32F469AIH6 is a high-performance ARM Cortex-M4 microcontroller from STMicroelectronics, designed for demanding applications that require rich graphics, advanced connectivity, and real-time control. Operating at up to 180 MHz, it delivers exceptional computational throughput. With 2MB of flash and 384KB of SRAM, it provides ample memory for complex applications. Its integrated LCD controller, I2S, and multiple communication interfaces make it a versatile choice for industrial, consumer, and medical products. The device operates from 1.7V to 3.6V, ensuring flexibility in power-sensitive designs.
- High-Performance Core: The 180MHz Cortex-M4 with FPU accelerates math-intensive tasks, reducing processing time for control loops and signal processing.
- Rich Graphics Support: Integrated TFT LCD controller and 2D accelerator enable smooth GUI development without external display drivers, lowering BOM cost.
- Large Memory: 2MB flash and 384KB RAM support complex firmware and data buffering, reducing the need for external memory.
- Low Power Flexibility: Wide voltage range (1.7V-3.6V) and multiple low-power modes extend battery life in portable devices.
- Comprehensive Security: Includes hardware random number generator and cryptographic acceleration for secure IoT applications.
High-Resolution Industrial HMI Panels
With a built-in TFT LCD controller and 2MB flash, the STM32F469AIH6 can drive high-resolution graphical interfaces in industrial control panels, providing smooth rendering and ample storage for UI assets.
Smart Home Gateways
The 180MHz Cortex-M4 core with DSP instructions handles complex protocol stacks (Zigbee, Z-Wave, Wi-Fi) while the low-voltage operation (1.7V) supports battery-backed always-on functionality.
Portable Medical Devices
Its low power modes and wide voltage range make it ideal for handheld diagnostic tools, where the integrated DMA and PWM enable precise sensor data acquisition and motor control for pumps.
Advanced Motor Control Systems
The multiple timers and PWM channels, combined with the fast ADC, allow for field-oriented control of brushless DC motors in robotics and CNC machinery, ensuring high efficiency and low torque ripple.
Audio Processing and Playback
The I2S interface and 384KB RAM support high-quality audio codecs, making it suitable for voice-guided navigation systems or musical instruments with real-time effects.
Wearable Electronics
The compact UFBGA package and 1.7V operation enable slim, energy-efficient wearables like fitness trackers, where the WDT and brown-out reset ensure reliable operation.
- Q: What is the maximum clock speed of the STM32F469AIH6?
- A: The STM32F469AIH6 operates at up to 180 MHz.
- Q: What is the supply voltage range?
- A: It supports 1.7V to 3.6V, enabling low-power and battery-operated designs.
- Q: Does it have a built-in LCD controller?
- A: Yes, it includes an LCD parallel interface and a TFT controller for graphical displays.
- Q: How much flash and RAM does it have?
- A: It features 2MB of flash memory and 384KB of SRAM.
- Q: What package is available?
- A: It comes in a 169-ball UFBGA package.
