STMicroelectronics STM32F469NIH6TR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $46.84 | $46.84 |
| 15+ | $10.77 | $161.55 |
| 25+ | $10.54 | $263.50 |
| 50+ | $9.95 | $497.50 |
| 100+ | $8.78 | $878.00 |
| N+ | $1.76 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | STMicroelectronics |
| Product Series | STM32F4 |
| Packaging | Tray | NULL |
| Core Processor | ARM® Cortex®-M4 |
| Core Size | 32-Bit Single-Core |
| Speed | 180MHz |
| Connectivity | CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, SAI, SDIO, SPI, UART/USART, USB, USB OTG |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT |
| Number of I/O | 161 |
| Program Memory Size | 2MB (2M x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 384K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.7V ~ 3.6V |
| Data Converters | A/D 24x12b; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 216-TFBGA (13x13) |
| Package / Case | 216-TFBGA |
| ROHS |  |
The STMicroelectronics STM32F469NIH6TR is a high-performance 32-bit microcontroller based on the ARM Cortex-M4 core with FPU, operating at 180 MHz. It features 2 MB of Flash and 384 KB of RAM, providing ample resources for complex applications. The device includes a TFT LCD controller, DMA, I2S, PWM, and comprehensive safety features. Packaged in a 216-TFBGA, it operates from -40°C to 85°C, making it suitable for advanced consumer, industrial, and medical applications requiring graphical displays and high-speed processing.
- Integrated LCD Controller: Directly drives TFT displays, reducing external components and BOM cost.
- High Memory Capacity: 2 MB Flash and 384 KB RAM support large applications and graphics buffers.
- Advanced DSP Capabilities: Cortex-M4 with FPU accelerates signal processing and mathematical computations.
- Rich Peripheral Set: DMA, I2S, PWM, and multiple communication interfaces enhance design flexibility.
- Compact BGA Package: 216-TFBGA enables high-density PCB layouts for miniaturized products.
Human-Machine Interfaces (HMI)
The integrated TFT LCD controller and 2 MB Flash enable rich graphical user interfaces on industrial panels and smart appliances.
Wearable Devices
Low-power modes and compact BGA package support smartwatches and fitness trackers with advanced sensor processing.
Audio Processing
I2S and DMA facilitate high-quality audio playback and voice recognition in smart speakers and hearing aids.
Industrial Automation
180 MHz Cortex-M4 with FPU handles complex control algorithms and predictive maintenance analytics.
Medical Imaging
Large RAM and high-speed processing support portable ultrasound and patient monitoring devices.
IoT Edge Nodes
Rich connectivity options and security features enable secure data aggregation and local decision-making.
- Q: What core does the STM32F469NIH6TR use?
- A: It is based on the ARM Cortex-M4 core with FPU, running at 180 MHz.
- Q: Does it have a built-in LCD controller?
- A: Yes, it includes a TFT LCD controller, making it ideal for GUI applications.
- Q: What is the memory capacity?
- A: It offers 2 MB Flash and 384 KB RAM, supporting complex applications and graphics buffers.
- Q: What is the operating temperature range?
- A: It operates from -40°C to 85°C (TA), suitable for consumer and industrial environments.
- Q: What package is available?
- A: It comes in a 216-TFBGA package, offering high pin count for rich connectivity.
