STMicroelectronics STM32L152R6H6A
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $11.88 | $11.88 |
| 15+ | $2.73 | $40.95 |
| 25+ | $2.67 | $66.75 |
| 50+ | $2.52 | $126.00 |
| 100+ | $2.23 | $223.00 |
| N+ | $0.45 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | STMicroelectronics |
| Product Series | STM32L1 |
| Packaging | Tray | NULL |
| Core Processor | ARM® Cortex®-M3 |
| Core Size | 32-Bit Single-Core |
| Speed | 32MHz |
| Connectivity | I2C, IrDA, LINbus, SPI, UART/USART, USB |
| Peripherals | Brown-out Detect/Reset, Cap Sense, DMA, I2S, LCD, POR, PWM, WDT |
| Number of I/O | 51 |
| Program Memory Size | 32KB (32K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| RAM Size | 16K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Data Converters | A/D 20x12b; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 64-TFBGA (5x5) |
| Package / Case | 64-TFBGA |
| ROHS |  |
The STM32L152R6H6A from STMicroelectronics is a 32-bit ARM Cortex-M3 microcontroller running at 32MHz. It offers 32KB flash and 16KB RAM in a 64-TFBGA package. Operating from 1.8V to 3.6V, it integrates an LCD driver, capacitive sensing, DMA, I2S, POR, PWM, and WDT, making it ideal for low-power applications with display and touch interfaces.
- Integrated LCD driver: Eliminates external display controller, saving cost and space.
- Capacitive touch support: Enables modern user interfaces without additional ICs.
- Low-power design: 1.8V operation and efficient Cortex-M3 extend battery life.
- Rich peripherals: DMA, I2S, and PWM provide flexibility for complex applications.
Medical Monitoring Devices
Low-power Cortex-M3 with LCD driver enables wearable heart rate or SpO2 monitors with direct display.
Industrial HMIs
Cap Sense and LCD support touch panels for machine control interfaces.
Smart Meters
DMA and I2S facilitate efficient data logging and communication with metering ICs.
Portable Instrumentation
16KB RAM and 32MHz speed handle multimeter or data logger algorithms with graphical LCD.
Building Security Panels
Cap Sense buttons and LCD display create intuitive keypads for access control systems.
- Q: What is the core and speed?
- A: ARM Cortex-M3 at 32MHz.
- Q: Supply voltage?
- A: 1.8V to 3.6V.
- Q: Memory?
- A: 32KB flash and 16KB RAM.
- Q: Special features?
- A: LCD driver, capacitive sensing, DMA, I2S.
