STMicroelectronics STM8L101F1U6ATR
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.86 | $1.86 |
| 15+ | $1.22 | $18.30 |
| 25+ | $1.20 | $30.00 |
| 50+ | $1.13 | $56.50 |
| 100+ | $1.00 | $100.00 |
| N+ | $0.20 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | STMicroelectronics |
| Product Series | STM8L EnergyLite |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Core Processor | STM8 |
| Core Size | 8-Bit |
| Speed | 16MHz |
| Connectivity | I2C, SPI, UART/USART |
| Peripherals | Infrared, POR, PWM, WDT |
| Number of I/O | 18 |
| Program Memory Size | 2KB (2K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 1.5K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.65V ~ 3.6V |
| Data Converters | - |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification AEC | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 20-UFQFPN (3x3) |
| Package / Case | 20-UFQFN |
| ROHS |  |
The STM8L101F1U6ATR from STMicroelectronics is an ultra-low-power 8-bit MCU featuring a 16MHz STM8 core, 2KB flash, and 1.5KB SRAM. Housed in a 20-UFQFN package, it operates from 1.65V to 3.6V and includes an infrared transmitter, PWM, POR, and WDT. Designed for energy-efficient applications, it excels in battery-powered and portable devices.
- Ultra-low voltage (1.65V): Enables operation from a single alkaline cell or Li-ion battery near end-of-charge.
- Integrated IR transmitter: Eliminates external IR driver components for remote control designs.
- Compact 20-UFQFN: Saves board space in miniaturized consumer and medical devices.
- 16MHz performance: Provides sufficient throughput for real-time control and communication protocols.
Remote Controls
The integrated infrared transmitter and 16MHz CPU enable IR remote control protocols for TVs, ACs, and set-top boxes.
Wearable Fitness Trackers
Ultra-low supply voltage (1.65V) and small 20-UFQFN package allow integration into slim wearable devices with minimal power draw.
Smart Home Sensors
Its low-power modes and PWM outputs are ideal for occupancy sensors and smart thermostats communicating over I2C or SPI.
Portable Medical Monitors
The 1.5KB RAM can buffer sensor data for temperature or heart-rate monitors while maintaining long battery life.
Industrial Timers
With a watchdog timer and wide temperature range, it can serve as a reliable timer/counter in factory automation equipment.
Consumer Electronics
Its small footprint and low cost make it suitable for toys, small appliances, and electronic greeting cards.
- Q: What is the core architecture of the STM8L101F1U6ATR?
- A: It uses the STM8 8-bit core running at up to 16MHz.
- Q: What is the supply voltage range?
- A: It operates from 1.65V to 3.6V, suitable for low-voltage battery applications.
- Q: How much RAM is available?
- A: It has 1.5KB of SRAM and 2KB of flash memory.
- Q: Does it support PWM output?
- A: Yes, it includes PWM channels and an infrared (IR) transmitter module.
