Texas Instruments THS1408IPFB
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $134.03 | $134.03 |
| 15+ | $30.83 | $462.45 |
| 25+ | $30.16 | $754.00 |
| 50+ | $28.48 | $1,424.00 |
| 100+ | $25.13 | $2,513.00 |
| N+ | $5.03 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Marketplace | Tray |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 8M |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | Parallel |
| Configuration | PGA-S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | Pipelined |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 3V ~ 3.6V |
| Voltage - Supply, Digital | 3V ~ 3.6V |
| Features | PGA |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Grade | - |
| Qualification | - |
| Package / Case | 48-TQFP |
| Supplier Device Package | 48-TQFP (7x7) |
| ROHS |  |
The THS1408IPFB from Texas Instruments is a high-speed 14-bit analog-to-digital converter featuring a programmable gain amplifier (PGA) and sample-and-hold (S/H) front end. With a sampling rate of 8 MSPS and a parallel interface, this ADC delivers excellent dynamic performance for demanding applications. It supports both external and internal references, providing design flexibility. Housed in a compact 48-TQFP package, it operates from 0°C to 70°C, making it ideal for industrial, medical, and communication systems.
- High-Speed Performance: 8 MSPS sampling rate enables real-time digitization of fast analog signals.
- Integrated PGA: Programmable gain amplifier allows signal conditioning without external components.
- Flexible Reference: Supports both external and internal references for design versatility.
- Compact Package: 48-TQFP package saves board space in space-constrained designs.
High-Speed Data Acquisition
The 8 MSPS sampling rate and 14-bit resolution make the THS1408IPFB ideal for high-speed data acquisition systems in test and measurement equipment.
Medical Imaging
With its PGA front-end and high-speed conversion, this ADC is suitable for ultrasound and other medical imaging applications requiring fast, accurate signal digitization.
Communications Systems
The parallel interface and high sampling rate enable use in base station receivers and other communication infrastructure where speed is critical.
Industrial Automation
Its internal reference and PGA allow for flexible integration into industrial automation systems for monitoring and control of analog sensors.
Portable Instrumentation
The 48-TQFP package and 0-70°C operating range make it suitable for portable test instruments that require high performance in a compact form factor.
- Q: What is the resolution of the THS1408IPFB?
- A: It is a 14-bit analog-to-digital converter.
- Q: What is the sampling rate of this ADC?
- A: The THS1408IPFB supports a sampling rate of 8 MSPS (8M samples per second).
- Q: How many channels does it have?
- A: It has a single (1) input channel.
- Q: What interface does it use?
- A: It uses a parallel interface for data output.
- Q: What is the architecture of this device?
- A: It features a PGA-S/H-ADC architecture with both external and internal reference options.
- Q: What package is available?
- A: It comes in a 48-TQFP package.
