Texas Instruments TLV70710PDQNT
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $0.79 | $0.79 |
| 15+ | $0.76 | $11.40 |
| 25+ | $0.75 | $18.75 |
| 50+ | $0.71 | $35.50 |
| 100+ | $0.62 | $62.00 |
| N+ | $0.12 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Texas Instruments |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | 1V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.36V @ 150mA |
| Current - Output | 200mA |
| Current - Quiescent (Iq) | 50 µA |
| Current - Supply (Max) | - |
| PSRR | 70dB ~ 50dB (100Hz ~ 1MHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature, Short Circuit, Reverse Polarity |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-XDFN Exposed Pad |
| Supplier Device Package | 4-X2SON (1x1) |
| ROHS |  |
The TLV70710PDQNT from Texas Instruments is a fixed 1.0V low-dropout linear regulator delivering up to 200mA. With a typical quiescent current of only 50µA and dropout of 0.36V at 150mA, it is optimized for battery-powered applications. The 4-X2SON package measures just 1x1mm, ideal for space-constrained designs. Its high PSRR (70dB at 100Hz) ensures clean output for sensitive analog and RF circuits.
- Ultra-compact footprint: 1x1mm X2SON package saves PCB space for miniaturized designs.
- Low quiescent current: 50µA extends battery life in always-on applications.
- High PSRR: 70dB at 100Hz rejects power supply noise for sensitive loads.
- Low dropout: 0.36V at 150mA maximizes headroom in low-voltage systems.
Battery-Powered IoT Sensors
The 1.0V output and 200mA capability are ideal for low-power MCUs in wireless sensor nodes. The 50µA quiescent current extends battery life during sleep modes.
Portable Medical Devices
Stable 1.0V rail for precision analog front-ends. The 70dB PSRR at 100Hz rejects mains hum, ensuring accurate biosignal measurements.
Wearable Electronics
The ultra-small 1x1mm X2SON package fits constrained PCB layouts in smartwatches and fitness bands. Low dropout of 0.36V maximizes efficiency from single-cell batteries.
FPGA Core Supplies
Provides clean 1.0V core voltage for low-power FPGAs. The 200mA current handles transient loads while maintaining regulation.
RF Transceivers
Excellent PSRR up to 1MHz (50dB) filters high-frequency noise from switching regulators, improving RF signal integrity in Bluetooth and Zigbee modules.
Industrial Sensors
Reliable 1.0V reference for analog sensor conditioning circuits. The low quiescent current reduces self-heating, improving measurement accuracy.
- Q: What is the output voltage of the TLV70710PDQNT?
- A: The fixed output voltage is 1.0V.
- Q: What is the maximum output current?
- A: It can deliver up to 200mA.
- Q: What is the input voltage range?
- A: The input voltage range is from 1.0V to 5.5V (based on 1V input spec).
- Q: What is the dropout voltage?
- A: Dropout is typically 0.36V at 150mA load.
- Q: What is the quiescent current?
- A: Quiescent current is typically 50 µA.
- Q: What package is available?
- A: It comes in a 4-X2SON (1x1mm) package.
