3PEAK TPL855650Q-TSCR-S
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $3.74 | $3.74 |
| 15+ | $0.86 | $12.90 |
| 25+ | $0.85 | $21.25 |
| 50+ | $0.80 | $40.00 |
| 100+ | $0.71 | $71.00 |
| N+ | $0.14 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | 3PEAK |
| Product Series | TPL8556Q |
| Packaging | Tape & Reel (TR) | |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 42V |
| Voltage - Output (Min/Fixed) | 5V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.8V @ 500mA |
| Current - Output | 500mA |
| Current - Quiescent (Iq) | 28 μA |
| Current - Supply (Max) | - |
| PSRR | 60dB (1MHz), 65dB ~ 40dB (100Hz ~ 100kHz) |
| Control Features | Delay, Enable, Power Good, Watchdog |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 28-ETSSOP |
| ROHS |  |
The TPL855650Q-TSCR-S from 3PEAK is a fixed 5V LDO delivering 500mA. It features an ultra-low 28 μA quiescent current and excellent PSRR of 60dB at 1MHz. The 28-ETSSOP package supports high-power automotive and industrial applications.
- Ultra-Low Quiescent Current: 28 μA ideal for battery and always-on systems.
- High PSRR at 1MHz: 60dB rejection of high-frequency noise for clean 5V rails.
- 500mA Output: Supports higher-current loads than typical LDOs.
- Low Dropout: 0.8V at 500mA maintains regulation under load.
Automotive ECU Power
Provide stable 5V to engine control units, with 60dB PSRR at 1MHz rejecting high-frequency switching noise.
Industrial PLC Modules
Power 5V logic and analog circuits in programmable logic controllers, ensuring reliable operation in noisy factories.
5V Sensor Arrays
Supply clean 5V to multiple sensors, with low 28 μA quiescent current for always-on sensing.
Battery-Powered Test Equipment
Regulate 5V for portable multimeters or oscilloscopes, maximizing battery runtime.
Communication Interfaces
Power CAN transceivers or RS-485 drivers with stable 5V, reducing data errors.
LED Display Drivers
Provide 5V to display driver ICs, with high PSRR preventing flicker from switching regulators.
