3PEAK TPL9208AD-QF7R-S
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $4.43 | $4.43 |
| 15+ | $4.29 | $64.35 |
| 25+ | $4.19 | $104.75 |
| 50+ | $3.96 | $198.00 |
| 100+ | $3.50 | $350.00 |
| N+ | $0.70 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | 3PEAK |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 6.5V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Voltage - Output (Max) | 5.2V |
| Voltage Dropout (Max) | 0.2V @ 2A |
| Current - Output | 2A |
| Current - Quiescent (Iq) | 15 mA |
| Current - Supply (Max) | 15 mA |
| PSRR | 63dB ~ 60dB (1kHz ~ 1MHz) |
| Control Features | Current Limit, Enable, Power Good, Soft Start |
| Protection Features | Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 20-WQFN Exposed Pad |
| Supplier Device Package | 20-QFN (5x5) |
| ROHS |  |
The TPL9208AD-QF7R-S from 3PEAK is a high-current LDO regulator delivering a fixed 5.2V output with up to 2A of current. It features a low dropout voltage of 0.2V at full load, making it highly efficient for high-current applications. With a PSRR of 63dB to 60dB (1kHz-1MHz) and a quiescent current of 15mA, this regulator is designed for demanding industrial and automotive environments, housed in a 20-QFN (5x5) package.
- High Output Current: 2A capability supports power-hungry loads like FPGAs and processors.
- Low Dropout: 0.2V at 2A ensures efficient operation with minimal power loss.
- Good PSRR: 63dB to 60dB rejection up to 1MHz maintains signal integrity.
- Compact QFN Package: 20-QFN (5x5) offers excellent thermal performance in a small footprint.
High-Current 5V Rails
With 2A output capability and a low dropout of 0.2V, this regulator is ideal for powering high-current 5V loads such as FPGAs, processors, and motor drivers.
Automotive Infotainment
The robust 2A output and 63dB PSRR make it suitable for automotive infotainment systems that require stable 5.2V power for displays and audio amplifiers.
Industrial Actuators
This LDO can drive industrial actuators and solenoids that need a regulated 5.2V supply with high current capability and low dropout.
Networking Equipment
For networking switches and routers, the TPL9208AD provides reliable 5.2V power to PHYs and switch ICs, with good noise rejection up to 1MHz.
Power Supply Post-Regulation
It can be used as a post-regulator after a DC-DC converter to provide a clean, low-noise 5.2V rail for sensitive analog and digital circuits.
