Taiwan Semiconductor Corporation TS2940CP33 ROG
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $2.31 | $2.31 |
| 15+ | $2.24 | $33.60 |
| 25+ | $2.19 | $54.75 |
| 50+ | $2.07 | $103.50 |
| 100+ | $1.82 | $182.00 |
| N+ | $0.36 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Taiwan Semiconductor Corporation |
| Product Series | |
| Packaging | Cut Tape (CT) | Tape & Reel (TR) |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 26V |
| Voltage - Output (Min/Fixed) | 3.3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.8V @ 800mA |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 15 mA |
| Current - Supply (Max) | 110 mA |
| PSRR | - |
| Control Features | - |
| Protection Features | Over Voltage, Thermal Shutdown, Transient Voltage |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-252 (DPAK) |
| ROHS |
The TS2940CP33 ROG from Taiwan Semiconductor is a fixed 3.3V low dropout linear regulator capable of delivering 1A of output current. Housed in a compact TO-252 (DPAK) package, it features a dropout voltage of just 0.8V at 800mA, making it efficient for systems with tight headroom. With a quiescent current of 15 mA, this regulator balances performance and power consumption for industrial and consumer applications.
- High Current Capacity: 1A output supports power-hungry peripherals and multi-rail systems without additional pass transistors.
- Low Dropout Voltage: 0.8V at 800mA enables operation from 4.1V input for a 3.3V output, extending battery life.
- Thermal Efficiency: TO-252 package offers excellent heat dissipation for sustained 1A loads.
- Fixed Output Accuracy: 3.3V fixed output eliminates external resistor dividers, reducing BOM count and design complexity.
Microcontroller Power Supply
Provides a stable 3.3V rail for MCUs and digital logic, with 1A capacity to handle transient loads and peripheral current spikes.
Battery-Powered Devices
The 15 mA quiescent current is moderate, making it suitable for applications where the load is consistently above 100mA, such as motor drivers or sensor arrays.
Industrial Sensor Interfaces
Delivers clean 3.3V power to analog sensors and ADCs, reducing noise-induced measurement errors with its low dropout performance.
Automotive Infotainment
With a TO-252 package and 1A output, it can power display panels and audio codecs in 12V vehicle systems when paired with a pre-regulator.
Networking Equipment
Provides a dedicated 3.3V rail for Ethernet PHYs and switches, ensuring reliable operation under varying line and load conditions.
LED Lighting Control
Regulates power for LED driver ICs in constant-current topologies, maintaining consistent brightness across input voltage fluctuations.
- Q: What is the output voltage of the TS2940CP33 ROG?
- A: The fixed output voltage is 3.3V.
- Q: What is the maximum output current?
- A: It can deliver up to 1A of continuous output current.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; refer to the datasheet for absolute maximum ratings.
- Q: What is the dropout voltage?
- A: The dropout voltage is 0.8V at 800mA load.
- Q: What is the quiescent current?
- A: The quiescent current is 15 mA.
- Q: What package is available?
- A: It comes in a TO-252 (DPAK) surface-mount package.
- Q: What is the output voltage of the TS2940CP33 ROG?
- A: The fixed output voltage is 3.3V.
- Q: What is the maximum output current?
- A: It can deliver up to 1A of continuous output current.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; refer to the datasheet for absolute maximum ratings.
- Q: What is the dropout voltage?
- A: The dropout voltage is 0.8V at 800mA load.
- Q: What is the quiescent current?
- A: The quiescent current is 15 mA.
- Q: What package is available?
- A: It comes in a TO-252 (DPAK) surface-mount package.

TS2940CP33 ROG.pdf
