STMicroelectronics VIPER35HE
Regular price
Dhs. 2.17
Regular price
Dhs. 2.29
Sale price
Dhs. 2.17
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | Dhs. 2.17 | Dhs. 2.17 |
| 15+ | Dhs. 2.11 | Dhs. 31.65 |
| 25+ | Dhs. 2.06 | Dhs. 51.50 |
| 50+ | Dhs. 1.95 | Dhs. 97.50 |
| 100+ | Dhs. 1.72 | Dhs. 172.00 |
| N+ | Dhs. 0.34 | Price Inquiry |
Shipping calculated at checkout.
Request Quote / Inquiry
VIPER35HE - High-Efficiency Offline Switching Power IC
The VIPER35HE from STMicroelectronics is a high-performance 22W flyback converter IC designed for isolated AC-DC power supplies. Featuring an integrated 800V power MOSFET and advanced protection features, this IC delivers reliable performance for industrial, telecom, and consumer applications requiring long lifecycle support and full traceability.
Key Features
- 22W Power Output with flyback topology for efficient isolated power conversion
- 800V Breakdown Voltage for high-voltage applications
- 225kHz Switching Frequency enabling compact transformer design
- Comprehensive Protection: Current limiting, over-temperature, over-voltage, and short-circuit protection
- Wide Operating Range: 8.5V to 23.5V supply voltage, -40°C to 150°C junction temperature
- Through-Hole 10-DIP Package for reliable board assembly and easy replacement
- RoHS/REACH Compliant with full manufacturer traceability
Applications
Ideal for aerospace, automotive, industrial control, medical equipment, and telecommunications systems requiring high-reliability components with long lifecycle commitments.
All specifications are sourced from the original manufacturer documentation. Full traceability and compliance certificates available upon request.
| Product attributes | Property Value |
| Manufacturer | STMicroelectronics |
| Product Series | |
| Packaging | Tube | |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 800V |
| Topology | Flyback |
| Voltage - Start Up | 14 V |
| Voltage - Supply (Vcc/Vdd) | 8.5V ~ 23.5V |
| Duty Cycle | - |
| Frequency - Switching | 225kHz |
| Power (Watts) | 22 W |
| Fault Protection | Current Limiting, Over Temperature, Over Voltage, Short Circuit |
| Control Features | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 10-DIP (0.300", 7.62mm) |
| Supplier Device Package | 10-SDIP |
| ROHS |  |
VIPER35HE.pdf
×
