Torex Semiconductor Ltd XC6220A12BPR-G
| Quantity | Unit Price | Total Price |
|---|---|---|
| 1 | $1.82 | $1.82 |
| 15+ | $0.41 | $6.15 |
| 25+ | $0.41 | $10.25 |
| 50+ | $0.38 | $19.00 |
| 100+ | $0.34 | $34.00 |
| N+ | $0.07 | Price Inquiry |
Request Quote / Inquiry
| Product attributes | Property Value |
| Manufacturer | Torex Semiconductor Ltd |
| Product Series | |
| Packaging | Tape & Reel (TR) | |
| Output Configuration | Active |
| Output Type | Positive |
| Number of Regulators | Fixed |
| Voltage - Input (Max) | 6V |
| Voltage - Output (Min/Fixed) | 1.25V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.46V @ 1A |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 18 μA |
| Current - Supply (Max) | 108 μA |
| PSRR | 50dB (1kHz) |
| Control Features | Enable |
| Protection Features | Over Current, Over Temperature |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | SOT-89-5/6 |
| Supplier Device Package | SOT-89-5 |
| ROHS |  |
The Torex XC6220A12BPR-G is a fixed-output low dropout linear regulator delivering a precise 1.25V rail at up to 1A. Its low 18 μA quiescent current and 0.46V dropout voltage make it ideal for battery-operated devices. The SOT-89-5 package balances thermal performance with a compact footprint, while 50dB PSRR at 1kHz ensures clean power for noise-sensitive circuits.
- Extended Battery Life: Ultra-low 18 μA quiescent current reduces standby drain in portable electronics.
- High Efficiency at Low Dropout: 0.46V dropout at 1A allows operation from a 1.8V rail with minimal power loss.
- Stable Output: 50dB PSRR at 1kHz suppresses input noise, protecting sensitive loads.
- Thermally Efficient Package: SOT-89-5 dissipates heat effectively for 1A continuous operation.
Battery-Powered IoT Sensors
With a low quiescent current of 18 μA, the XC6220A12BPR-G minimizes standby power consumption, extending battery life in wireless sensor nodes that spend most of their time in sleep mode.
Portable Medical Devices
The stable 1.25V output and 1A current capability support sensitive analog front-ends in portable diagnostic equipment, ensuring consistent performance despite varying load conditions.
FPGA Core Power Supply
Modern FPGAs often require a low-voltage core supply. This regulator provides a clean 1.25V rail with a dropout of only 0.46V, allowing efficient operation from a 1.8V or 2.5V input bus.
Industrial Control Modules
The SOT-89-5 package offers good thermal dissipation for 1A loads in space-constrained industrial controllers, providing a reliable power source for microcontrollers and interface circuits.
Audio Equipment Bias Supply
The 50dB PSRR at 1kHz helps reject power supply noise, making it suitable for biasing audio codecs and op-amps in portable audio players where signal integrity is critical.
Automotive Telematics Units
Although not AEC-Q100 qualified, the robust SOT-89-5 package and 1A output make it a candidate for aftermarket telematics modules requiring a stable 1.25V reference for communication processors.
- Q: What is the output voltage of the XC6220A12BPR-G?
- A: The fixed output voltage is 1.25V.
- Q: What is the maximum output current?
- A: It can deliver up to 1A of continuous output current.
- Q: What is the input voltage range?
- A: The input voltage range is not specified in the provided data; please refer to the datasheet.
- Q: What is the dropout voltage?
- A: The dropout voltage is 0.46V at a 1A load.
- Q: What is the quiescent current?
- A: The quiescent current is a low 18 μA, making it suitable for battery-powered devices.
- Q: What package is available?
- A: It comes in a SOT-89-5 package.
